Sigen Sensor TP-DH

Item number: C00676

Warranty: 2 years

The Sigen Sensor TP-DH (Sigen Power Sensor) is a three-phase (3P3W/3P4W) energy monitoring and metering device designed for seamless integration with Sigenergy systems. With fast (100 ms) data updates, it provides real-time feedback, and basic information can be checked immediately on its LCD display. Measurement accuracy is 1% on the power side, enabling precise control and support for import/export restrictions.

Main features

• Performance measurement: 1% accuracy
• LCD display: real-time information display
• System integration: Can be integrated with Sigenergy devices without any special configuration
• Data refresh: 100 ms
• Support for import/export restrictions, "AI evolving" compatibility

Technical data

• Network connection type: 3P3W / 3P4W
• AC input voltage range: 173–480 Vac
• Nominal AC frequency: 50/60 Hz
• Maximum operating current: 100 A

Measurement accuracy

• Voltage accuracy: 0.5%
• Current accuracy: 0.5%
• Power accuracy: 1%
• Frequency accuracy: 0.2%

Communication

• Interface: RS485
• Baud rate: 9600 bps
• Protocol: Modbus RTU

General information

• Dimensions (W / H / D): 72 / 100 / 66 mm
• Weight: 0.32 kg
• Storage temperature range: -40 ~ +85 °C
• Operating temperature range: -30 ~ +60 °C
• Relative humidity range: 0–90%
• Protection: IP51
• Mounting method: DIN rail (35 mm)

Standards

• EN 61010-1:2010, EN 61010-2-030:2010
